BLUE SEA INSULATED TERMINAL BLOCK 20A 2 CIRCUIT (BS-2402)

BLUE SEA INSULATED TERMINAL BLOCK 20A 2 CIRCUIT

$ 12.90 12.9 AUD $ 12.90

$ 12.90

This combination does not exist.

Fully insulated independent terminal blocks to isolate circuits

Features
• Each screw pair is one isolated circuit
• Terminal Block Jumpers allow creation of common circuits
• Closed back design insulates power from the mounting surface

BLA Code	Circuits	AC/DC Amps A	AC/DC Volts V	Terminal Screw	Length mm (A)	Mounting Centres mm (B)

BLA Code	Circuits	AC/DC Amps A	AC/DC Volts V	Terminal Screw	Length mm (A)	Mounting Centres mm (B)
BS-2402	2	20	300	#6	36	29
BS-2404	4	20	300	#6	55	48
BS-2406	6	20	300	#6	74	67
BS-2408	8	20	300	#6	93	86
BS-2410	10	20	300	#6	112	105
BS-2502	2	30	600	#8	54	43
BS-2504	4	30	600	#8	83	71
BS-2506	6	30	600	#8	111	100
BS-2510	10	30	600	#8	168	157
BS-2512	12	30	600	#8	197	186
BS-2602	2	65	600	#10	64	52
BS-2604	4	65	600	#10	99	87
BS-2606	6	65	600	#10	99	122
BS-2608	8	65	600	#10	134	157
BS-2610	10	65	600	#10	203	192

Accessories
BS-9218 Terminal Jumper For use with 20A Terminal Blocks (pack of 5)
BS-9217 Terminal Jumper For use with 30A Terminal Blocks (pack of 5)
BS-9216 Terminal Jumper For use with 65A Terminal Blocks (pack of 5)
