SIERRA CONTURA V SWITCH ON-OFF-ON SPDT ILLUMINATED (SRK19320)

Name: SIERRA CONTURA V SWITCH ON-OFF-ON SPDT ILLUMINATED (SRK19320)
Price: 41.9 AUD
Availability: InStock

SIERRA CONTURA V SWITCH ON-OFF-ON SPDT ILLUMINATED

$ 41.90

• Non-corrosive plastic construction
• Protects against dust and prolonged spray to IP66 and IP68 standards
• Meets UL 1500, ISO 8846 ignition protection requirements
• Supplied with neoprene mounting gasket
• Removable actuators
• Brass blade terminals, silver contacts – Rated 20 amps @12 VDC

BLA Code	Switch	Throw	Face Size mm	Cut Out mm	Intrusion mm	Illumination

BLA Code	Switch	Throw	Face Size mm	Cut Out mm	Intrusion mm	Illumination
SRK19210	On-Off	SPST	25x50	21x37	38	-
SRK19220	On-Off-On	SPST	25x50	21x37	38	-
SRK19230	Off- (On)	SPST	25x50	21x37	38	-
SRK19240	(On)-Off-(On)	DPST	25x50	21x37	38	-
SRK19310	On-Off	SPST	25x50	21x37	38	1
SRK19320	On-Off-On	SPST	25x50	21x37	38	2
